Fixed Mount Barcode Scanner

Fixed Mount Barcode Scanner - 2D FS5020ML

Model : FS5020ML - 2D Engine (RIOTEC 2D)

Q'ty :

fixed-mount-barcode-scanner-fs5020ml-2d-200206-02.pdf

FS5020ML 2D Fixed-mount barcode scanner for production line or conveyor system
* Easy installation
* Sensor (1280 x 1024 pixels) can read Code-39 3mil
* Motion tolerance 3.0 m/sec
* Rugged aluminum housing
* Read 1D/2D barcodes on paper or on the screen quickly
* Presentation-mode
* Interface: USB HID, USB-Serial, RS232

Specifications
Description

FS5020ML is a 2D Fixed-mount barcode scanner for production line or conveyor system

The FS5020ML represents the premium level of data collection devices. Using advanced 2D imaging technology, FS5020ML 2D fixed-mount barcode reader provides a solution for OEM use into self-service kiosks, price checker, ticket readers, document handling, as well as vending machines.
Designed for easy integration, the FS5020ML 2D Fixed-mount barcode scanner provides a plug-and-play solution for system designers.
The FS5020ML features outstanding reading, high motion tolerance, snappy reading, and also offers excellent performance on some DPM codes. .

Advantages:
* Easy installation
* Sensor (1280 x 1024 pixels) can read Code-39 3mil
* Motion tolerance 3.0 m/sec: can read the moving barcodes quickly.
* Rugged aluminum housing
* Read 1D/2D barcodes on paper or on the screen quickly
* Presentation-mode
* Interface: USB HID, USB-Serial, RS232
* FS5020ML has the excellent reading performance as FS5020M, but its reading distance is longer than FS5020M.

	Specifications :
	Model Name	FS5020ML
	Description	2D Fixed-mount barcode scanner
	Engine	High speed 2D engine
	Performance Characteristics
˙	Motion Tolerance	3.0m/sec
˙	Scan speed	60 frame /sec
˙	Light source	620nm Red LED
˙	Depth of field	(13 mil UPC-A)：500 mm
˙	Sensor	CMOS (1280×1024 pixels)
˙	Best resolution	1D (3mil)：Code 39
˙	Reading angle	Tilt: 360° / Pitch ±60° / Skew ±70°
˙	Print contrast	≥ 20%
˙	Indicators	LED & Beeper
˙	Symbologies	1D: EAN-8, EAN-13, ISSN, ISBN, UPC-A, UPC-E, Code 11, Code 32,Code 39, Code 93, Code 128, Codabar, industrial 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, GS1-128, GS1 Databar, GS1 DataBar Limited, GS1 DataBar Expanded 2D: PDF417, MicroPDF417, QR Code, Micro QR Code, Data Matrix, Aztec
˙	Interface	USB HID, USB Serial (by request), RS232 (by request)
	Electrical Characteristics
˙	Input voltage	5 V/DC ± 5%
˙	Current - operating	300 mA
	Physical Characteristics
˙	Dimension	60 X 54 X 30 mm
˙	Weight	184g +/- 5 g (with cable and stand)
˙	Case material	Aluminum & ABS plastic
	Environment
˙	Temperature-operation	0°C to 50°C
˙	Temperature-storage	-10°C to 60°C
˙	Humidity-operation	5% to 95% relative humidity, non-condensing
˙	Ambient Light	0-70000 Lux
	Decode Zone (DOF is measured at the office under 600 lux and by Standard barcode. There are +/- 10 mm Torrence. DOF may be also impacted by barcode quality and environmental conditions. )
˙	4 mil Code 39	100mm - 200mm
˙	5 mil Code 39	90mm - 250mm
˙	13 mil UPC-A	65mm - 500mm
˙	20 mil QR Code	45mm - 400mm
˙	10 mil Datamatrix	100mm - 250mm
˙	6.67 mil PDF417	100mm - 220mm
