Barcode Scan Module - 2D SME560M

Model：SME560M - 2D Scan Module

SME560M- Fixed-mount 2D barcode scanner for production line or conveyor system
* Easy installation
* Sensor (1280 x 1024 pixels) can read Code-39 3mil
* Motion tolerance 3.0 m/sec
* Read 1D/2D barcodes on paper or on the screen quickly
* Interface: Micro USB, 1.25mm wafer 5pin, FPC 12pin

Q'ty：

RIOTEC's 2D Barcode Scan Module is a high-performance scanning solution, built for fast, reliable data collection. Featuring advanced 2D imaging technology, this module is designed for seamless integration into OEM devices like self-service kiosks, price checkers, ticket readers, and vending machines. With automatic barcode detection in presentation mode, it efficiently reads 1D/2D barcodes from both printed labels and smartphone screens. Its compact size and multiple communication options make installation straightforward, and its superior motion tolerance (up to 3.0 m/s) ensures quick and snappy barcode reading in various environments.

As a leading Taiwan manufacturer and barcode scanner manufacturer, RIOTEC offers the most advanced 2D scan engine solutions. Our 2D barcode scan module combines cutting-edge decoding performance with a compact design for easy integration into industrial equipment, healthcare systems, and more. It excels in reading 1D and 2D barcodes, including DPM codes, and handles high-speed motion tolerance for reliable use in dynamic environments like production lines and conveyor systems. RIOTEC’s modules offer enhanced performance, seamless integration, and industry-leading durability, making them a trusted choice across industries.

Ready to integrate our high-performance 2D Barcode Scan Module into your system? Contact RIOTEC, a trusted barcode scanner manufacturer.

Features

High-Performance Scanning: Reads 1D and 2D barcodes on printed labels or smartphone screens.
Omni-Directional Reading: Scans barcodes from any angle for maximum flexibility.
Compact Design: Seamlessly integrates into space-constrained OEM devices.
Rugged Housing Design: Durable construction for reliable use in demanding environments.
High Motion Tolerance: Handles speeds up to 3.0 m/s for fast-moving barcode environments.
Multiple Communication Interfaces: Supports Micro USB, 1.25 mm Wafer 5-pin, and FPC 12-pin.
DPM Code Capability: Reads Direct Part Marking (DPM) codes for precise traceability.
Easy Installation: Designed for fast, hassle-free OEM integration.

Scanners Specifications：
	Model Name	SME560M
	Description	Stationary 2D barcode scan module
	Engine		2D engine
	Scan Mode		Presentation mode
Performance Characteristics
˙	Motion Tolerance		3.0 m/sec
˙	Scan speed		60 frame /sec
˙	Light source		620nm Red LED
˙	Depth of field		13mil EAN13: 220 mm 20mil QR CODE: 200 mm
˙	Sensor		CMOS (1280×1024 pixels)
˙	Best resolution		1D (3mil)：Code 39
˙	Reading angle		Tilt: 360° / Pitch ±60° / Skew ±70°
˙	Print contrast		≥ 20% or more
˙	Indicators		LED & Beeper
˙	Symbologies		1D: EAN-8, EAN-13, ISSN, ISBN, UPC-A, UPC-E, Code 11, Code 32, Code 39, Code 93, Code 128, Codabar, industrial 2 of 5, Interleaved 2 of 5, Matrix 2 of 5, GS1-128, GS1 Databar, GS1 DataBar Limited,GS1 DataBar Expanded 2D: PDF417, Micro PDF417, QR Code, Micro QR Code, Data Matrix, Aztec
˙	Interface		USB HID, USB Serial (by request), RS232 (by request)
	connection port		micro USB / 1.25mm wafer 5pin / FPC 12pin
Electrical Characteristics
˙	Input voltage		5 V/DC ± 5%
˙	Current - operating		190 mA max
Physical Characteristics
˙	Dimension (L x W x H)		65.04 x 59 x 45.9 mm
˙	Weight		24 g +/- 5 g
	Case material		ABS Plastic
Environment
˙	Temperature-operation		-15°C to 55°C (This figure is when the module installed inside of the finished products)
˙	Temperature-storage		-30°C to 70°C (This figure is when the module installed inside of the finished products)
˙	Humidity-operation		up to 95% relative humidity, non-condensing
˙	Ambient Light		100,000 Lux max
Decode Zone (DOF is measured at the office under 600 lux and by Standard barcode. There are +/- 10 mm Torrence. DOF may be also impacted by barcode quality and environmental conditions. )
˙	4 mil Code39		10 - 90 mm
˙	5 mil Code39		10 - 110 mm
˙	13 mil UPC-A		10 - 220 mm
˙	6.67 mil PDF417		10 - 110 mm
˙	10 mil DataMatrix		10 - 100 mm
˙	20 mil QR Code		10 - 200 mm
